| Fundamental Characteristics | |
| CPU | Intel Celeron Processor J1900 (Bay-Trail) |
| System Memory | 1 x 204 pin DIMM socket up to 8GB DDR3L SDRAM |
| Storage | HDD(l x 2.5″ SATA drive) |
| Windows Embedded Professional 7 |
| Windows Embedded Standard 7 |
| Windows Embedded POSReady 7 |
| Operating System | Windows Embedded 8.1 Professional |
| Windows Embedded 8.1 Industry |
| ويندوز 10 لو المؤسسة 64 بت |
| Graphics | Intel Gen 7 Intel Graphics DX 11, OGL3.2 |
| Network | Realtek RTL8111G-CG 10/100/1000 |
| Audio | Realtek ALC662 HD codec |
| Physical Characteristics | |
| LCD: 15″ |
| Display | 1366×768 Resolution: 1024 x 768 |
| Brightness: 250 cd/㎡ (option :450 cd/㎡) |
| Touch Screen:10 points Projective Capacitive |
| Power Adapter | AC input: 100-240V,50-60Hz;DC output: 24V / 65W |
| LCD Tilting Angle:: 15° -90° |
| Physical Dimensions | Weight: 9 kg; w/ power adapter, printer (approximate) |
| Dimension: 205 (D) x 360 (W) x 426 (H) mm |
| Work Environments | |
| Operating Temperature | 0°-40°C |
| Storage Temp. | -20°~60°C |
| Humidity | 10%- 90% |
| External I/0 Ports | |
| USB Ports | 4 x USB 3.0 on the rear and 1 x USB 2.0 on the front |
| 3 x DB-9 (com 1, com 2, and com 3) |
| Serial Ports | com 1,com 2,and com 3 (RS-232 only) selectable via BIOS seting |
| All cams 5V and 12V selectable via jumper seting (default no power) |
| LAN | 1 x RJ-45 |
| PS/2 | 2 x PS/2 (mouse and keyboard) |
| Audio | 1*Line-out , 1 x mic in |
| VGA | 1 xDB-15 |
| Cash Drawer Port | 1 x RJ11 1 x RJ11 output (Printer model only) |
| optional | |
| Thermal Printer | Integrated 80/58 mm thermal printer, 200 mm/s auto cutter |
| MSR | Attached 3 tracks USB type |
| VFD | Attached 2 x 20 attached VFD |
| Display | Attached 10.4′; XGA 1024 x 768, USB type (Option: 7′; 8″) |
| Barcode Scanner | Integrated 1 D/2D barcode scanner (alternative of printer) |
| I-Button | Integrated 1 x I button reader |
