Description
| System | |||||
| Processor | Intel® Celeron J1900 Quad-Core processor (2.0 GHz) | Intel® Core i3-4010U Processor (1.7 GHz) | Intel® Core i5-4200U Processor (1.6 GHz) | ||
| System Memory | 2GB Standard, DDR3L 1333MHz (Max.8GB) | ||||
| Storage Device | 32GB Msata SSD Standard,1*2.5’’ HDD / 2.5’’ SSD | ||||
| OS Supported | Windows 7, Windows 8, Windows 10 IoT Enterprise, POS Ready 7, Linux | ||||
| Audio | Realtek ALC662 | ||||
| Display and Touch | |||||
| Type | 15” TFT LCD, LED Backlight | ||||
| Resolution | 1024×768 | ||||
| Touch Screen | Projected Capacitive Touch Screen | ||||
| Customer Display | LED (8C digital tube) | ||||
| External I/O Ports | |||||
| VGA | 1*DB-15 | ||||
| USB | 5*USB 2.0 & 1*USB 3.0 | 4*USB 2.0 & 2*USB 3.0 | 4*USB 2.0 & 2*USB 3.0 | ||
| Serial & HDMI | 1*RS232 (Max.4pcs | 1*HDMI & 3*RS232 | 1*HDMI & 3*RS232 | ||
| LAN | 1*RJ45 | ||||
| Audio | 1*Line-out | ||||
| Power | |||||
| Power Supply | Adaptor 12V DC 5A | ||||
| Physical Environment | |||||
| Operating Temperature | 0°C ~ 35°C at 20% – 80% Humidity | ||||
| Storage Temperature | -20°C ~ 55°C at 20% – 80% Humidity | ||||
| Dimensions (W×H×D) | 358*390*236mm | ||||
| Packing Dimensions | 460*490*315mm | ||||
| Net Weight | 6.8kg | ||||
| Packing Weight | 7.9kg | ||||
| Certification | CE, FCC | ||||
| Color | Silver | ||||
| Options & Peripherals | |||||
| 2nd Display | 15” TFT LCD | ||||
| Customer Display(VFD) | VFD (2*20 Lines) | ||||
| MSR | 3 Tracks | ||||
| Fingerprint | USB fingerprint reader | ||||
| Thermal Printer | Integrated 80/58mm thermal printer | ||||
