Description
| Display | 4.3-Inch Touch Screen |
| Face capacity | 3,000 (1:N) |
| Fingerprint capacity | 2,000 |
| ID Card capacity | 10,000 (optional) |
| Logs capacity | 100,000 |
| Communication | TCP/IP, RS232/485, USB Host |
| Standard Functions | ADMS, Automatic Status Switch, Self-Service Query, Work Code, SMS DST, T9 Input, 9 Digit User ID, Scheduled Bell, Photo ID |
| Interfaces for | 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm |
| Wiegand Signal | Output |
| Optional Functions | ID/MiFare Card, Wi-Fi, 3G, 2000 mAH Backup Battery |
| Power Supply | 12V 3A |
| Operating Temperature | 0 °C- 45 °C |
| Operating Humidity | 20%-80% |
| Dimensions | 195.5*166.5*120mm (Length*Width*Thickness) |
| Package Weight | 1.6 kg |
